Single Core Copper Earth Wire Cable for Grounding
Release time: 2024-02-19
APPLICATIONS
It is used for internal perimeter wiring between switchboards of electrical appliances and installations and power distributor wiring boards, interfaces between electronic and electrical equipment switch cabinets, designed to use semi-exposed and embedded conduits, flexible laying, and grounding wires, resistant to 90 °C high-temperature environment.
TECHNICAL CHARACTERISTICS
Voltage Rating: Uo/UH05V2-R: 300/500VH07V2-R: 450/750V
Temperature Rating:Fixed: -30°C to +90°CFlexed: -5°C to +70°C
Test Voltage:H05V2-R: 2KVH07V2-R:2.5KV
Minimum Bending Radius:
Fixed:15xD(overall diameter)Flexed:15xD(overall diameter)
Flame retardant: lEC 60332.1eInsulation resistance: 20 MΩ x km
Standards: RoHS CE
Single Core Copper Earth Wire Cable for Grounding
