MV cable: 11KV 33KV 3.6KV - 35KV Underground Power Cable

Application

Their aluminium wire armour (AWA) for single core cables and steel wire armour (SWA) for multicore cables provide robust mechanical protection making these MV cables suitable for direct burial in the ground. These armoured MV mains power cables are more commonly supplied with copper conductors but they are also available with aluminium conductors upon request to the same standard. The copper conductors are stranded (Class 2) whereas the aluminium conductors are compliant to the standard using both stranded and solid (Class 1) constructions.

Operating characteristics

1. Laying temperature: ≥0°C;

2. Cable conductor long-term allowable working temperature: PVC insulated ≤70°C, XLPE insulated ≤90°C;

3. Maximum operating temperature in case of short-circuit: PVC insulated ≤160°C, XLPE insulation ≤ 250°C;

4. Cable bending radius:


Item	Single-core		Three-core
Item	Non-armored	Armored	Non-armored	Armored
Installation	20D	15D	15D	12D
Close to the terminal and connection box	15D	12D	12D	10D

Note: D is the cable diameter

MV Cables Construction

	BS6622	BS7835
Conductor	Class 2 stranded copper or Class 1 solid /Class 2 stranded aluminium
Conductor Screen	Semi-conductive Cross-Linked Polyethylene (XLPE)
Insulation	XLPE
Insulation Screen	Semi-conductive XLPE
Metallic Screen	Individual or overall copper tape
Filler	Polyethylene Terephthalate (PET) fibres
Separator	Binding Tape
Bedding	Polyvinyl Chloride (PVC)	Low Smoke Zero Halogen (LSZH) compound
Armour	Single core cable: Aluminium Wire Armour (AWA) Multicore cable: Steel Wire Armour (SWA)
Sheath	PVC or Medium Density Polyethylene (MDPE)	LSZH

Cable models, names, and laying conditions


Model		Name	Laying Occasion
Copper core	Aluminum core	Name	Laying Occasion
YJV	YJLV	XLPE insulated PVC sheathed power cable	Laid indoors, and in tunnels and pipelines
YJY	YJLY	XLPE insulated PE sheathed power cable	Laid indoors, and in tunnels and pipelines
YJV22	YJLV22	XLPE insulated steel tape armored PVC sheathed power cable	Adapt for buried laying, not suitable for in-pipe laying
YJV23	YJLV23	XLPE insulated steel tape armored PE sheathed power cable	Adapt for buried laying, not suitable for in-pipe laying
YJV32	YJLV32	XLPE insulated thin steel wire armored PVC sheathed power cable	Laid on riverbeds of rivers or shallow water as connecting lines across rivers or petroleum/natural gas platforms, also used in land high drop areas.
YJV33	YJLV33	XLPE insulated thin steel wire armored PVC sheathed power cable
YJV42	YJLV42	XLPE insulated thick steel wire armored PVC sheathed power cable
YJV43	YJLV43	XLPE insulated thick steel wire armored PE sheathed power cable
W	VLV	PVC insulated and sheathed power cable	Laid indoors, and in tunnels, pipelines, cable trenches, and flammable and severe corrosion places, and can not bear external mechanical forces.
VY	VLY	PVC insulated PE sheathed power cable	Laid indoors, and in pipelines, cable trenches and severe corrosion places, and cannot bear external mechanical forces.
VV22	VLV22	PVC insulated steel tape armored PVC sheathed power cable	Laid indoors, and in cable trenches, underground severe corrosion places, and cannot bear tension.
VV23	VLV23	PVC insulated steel tape armored PE sheathed power cable	Laid indoors, and in cable trenches and underground severe corrosion place, and cannot bear tension.
VV32	VLV32	PVC insulated thin steel wire armored PVC sheathed power cable	Laid under ground and in shafts, water and severe corrosion places, and cannot bear high tension.
VV33	VLV33	PVC insulated thin steel wire armored PVC sheathed power cable	Laid under ground and in shafts, water and severe corrosion places, and can bear high tension
VV42	VLV42	PVC insulated thick steel wire armored PVC sheathed power cable	Laid under ground and in shafts and severe corrosion places, and can bear high tension.
VV43	VLV43	PVC insulated thick steel wire armored PE sheathed power cable	Laid under ground and in shafts and severe corrosion places, and can bear high tension.

Application

Their aluminium wire armour (AWA) for single core cables and steel wire armour (SWA) for multicore cables provide robust mechanical protection making these MV cables suitable for direct burial in the ground. These armoured MV mains power cables are more commonly supplied with copper conductors but they are also available with aluminium conductors upon request to the same standard. The copper conductors are stranded (Class 2) whereas the aluminium conductors are compliant to the standard using both stranded and solid (Class 1) constructions.

Operating characteristics

1. Laying temperature: ≥0°C;

2. Cable conductor long-term allowable working temperature: PVC insulated ≤70°C, XLPE insulated ≤90°C;

3. Maximum operating temperature in case of short-circuit: PVC insulated ≤160°C, XLPE insulation ≤ 250°C;

4. Cable bending radius:


Item	Single-core		Three-core
Item	Non-armored	Armored	Non-armored	Armored
Installation	20D	15D	15D	12D
Close to the terminal and connection box	15D	12D	12D	10D

Note: D is the cable diameter

MV Cables Construction

	BS6622	BS7835
Conductor	Class 2 stranded copper or Class 1 solid /Class 2 stranded aluminium
Conductor Screen	Semi-conductive Cross-Linked Polyethylene (XLPE)
Insulation	XLPE
Insulation Screen	Semi-conductive XLPE
Metallic Screen	Individual or overall copper tape
Filler	Polyethylene Terephthalate (PET) fibres
Separator	Binding Tape
Bedding	Polyvinyl Chloride (PVC)	Low Smoke Zero Halogen (LSZH) compound
Armour	Single core cable: Aluminium Wire Armour (AWA) Multicore cable: Steel Wire Armour (SWA)
Sheath	PVC or Medium Density Polyethylene (MDPE)	LSZH

Cable models, names, and laying conditions


Model		Name	Laying Occasion
Copper core	Aluminum core	Name	Laying Occasion
YJV	YJLV	XLPE insulated PVC sheathed power cable	Laid indoors, and in tunnels and pipelines
YJY	YJLY	XLPE insulated PE sheathed power cable	Laid indoors, and in tunnels and pipelines
YJV22	YJLV22	XLPE insulated steel tape armored PVC sheathed power cable	Adapt for buried laying, not suitable for in-pipe laying
YJV23	YJLV23	XLPE insulated steel tape armored PE sheathed power cable	Adapt for buried laying, not suitable for in-pipe laying
YJV32	YJLV32	XLPE insulated thin steel wire armored PVC sheathed power cable	Laid on riverbeds of rivers or shallow water as connecting lines across rivers or petroleum/natural gas platforms, also used in land high drop areas.
YJV33	YJLV33	XLPE insulated thin steel wire armored PVC sheathed power cable
YJV42	YJLV42	XLPE insulated thick steel wire armored PVC sheathed power cable
YJV43	YJLV43	XLPE insulated thick steel wire armored PE sheathed power cable
W	VLV	PVC insulated and sheathed power cable	Laid indoors, and in tunnels, pipelines, cable trenches, and flammable and severe corrosion places, and can not bear external mechanical forces.
VY	VLY	PVC insulated PE sheathed power cable	Laid indoors, and in pipelines, cable trenches and severe corrosion places, and cannot bear external mechanical forces.
VV22	VLV22	PVC insulated steel tape armored PVC sheathed power cable	Laid indoors, and in cable trenches, underground severe corrosion places, and cannot bear tension.
VV23	VLV23	PVC insulated steel tape armored PE sheathed power cable	Laid indoors, and in cable trenches and underground severe corrosion place, and cannot bear tension.
VV32	VLV32	PVC insulated thin steel wire armored PVC sheathed power cable	Laid under ground and in shafts, water and severe corrosion places, and cannot bear high tension.
VV33	VLV33	PVC insulated thin steel wire armored PVC sheathed power cable	Laid under ground and in shafts, water and severe corrosion places, and can bear high tension
VV42	VLV42	PVC insulated thick steel wire armored PVC sheathed power cable	Laid under ground and in shafts and severe corrosion places, and can bear high tension.
VV43	VLV43	PVC insulated thick steel wire armored PE sheathed power cable	Laid under ground and in shafts and severe corrosion places, and can bear high tension.
