Application
They are suitable for use in distribution installations, electric power stations and industrial systems. The cables are for fixed assembly in lines with unlimited difference levels, indoor installations, in cable ducts, conduits and shafts, over shelves and grills directly underground in ditch and outdoor shelter.
Standards
DIN VDE 0276part 620, HD 620 and IEC 60502
Construction
Conductor: Сu and Al stranded compacted, according to IEC 60228 class 2 or VDE 0295 class 2
Inner Layer: Semi-conductive material
Insulation: XLPE (Cross-Linked Polyethylene)
Outer Layer: Semi-conductive material and tape
Screen: Copper wires and copper tape
Outer Sheath: PVC (Polyvinyl Chloride) or PE
Sheath Colour: Red
Parameter
N2XSEY 6/10kV 3-core Cable
They are suitable for use in distribution installations, electric power stations and industrial systems. The cables are for fixed assembly in lines with unlimited difference levels, indoor installations, in cable ducts, conduits and shafts, over shelves and grills directly underground in ditch and outdoor shelter.
Standards
DIN VDE 0276part 620, HD 620 and IEC 60502
Construction
Conductor: Сu and Al stranded compacted, according to IEC 60228 class 2 or VDE 0295 class 2
Inner Layer: Semi-conductive material
Insulation: XLPE (Cross-Linked Polyethylene)
Outer Layer: Semi-conductive material and tape
Screen: Copper wires and copper tape
Outer Sheath: PVC (Polyvinyl Chloride) or PE
Sheath Colour: Red
Parameter
N2XSEY 6/10kV 3-core Cable
| Number of cores x core cross section | Thickness of insulation | Thickness of PVC sheathed | Approx diameter of cable | Approx. cable weight |
| mm2 | mm | mm | mm | kg/km |
| 3x25/16 | 3,4 | 2,5 | 43 | 2850 |
| 3x35/16 | 3,4 | 2,5 | 48 | 3300 |
| 3x50/16 | 3,4 | 2,5 | 50 | 3750 |
| 3x70/16 | 3,4 | 2,6 | 54 | 4650 |
| 3x95/16 | 3,4 | 2,8 | 58 | 5700 |
| 3x120/25 | 3,4 | 2,9 | 61 | 6700 |
| 3x150/25 | 3,4 | 3,0 | 65 | 7900 |
| 3x185/25 | 3,4 | 3,1 | 68 | 9200 |
| 3x240/25 | 3,4 | 3,3 | 74 | 11450 |
| 3x300/25 | 3,4 | 3,3 | 79 | 14450 |
